Receiving Card MRV328

Product No : MRV328

Update Time : 22 April 2020

฿0.00

The MRV328 is a new receiving card developed by NovaStar. A single MRV328 loads up to 256x256 pixels.
The MRV328 supports pixel level brightness and chroma calibration, which effectively removes color difference, greatly improves display consistency of LED images, and presents finer displays to users.
Software and hardware designs of the MRV328 have fully concerned users' deployment, operating and maintenance scenarios, enabling easier deployment, more stable operating and more efficient maintenance.

Hardware design:

 Integrates 8 standard HUB75 connectors, which makes the HUB board unnecessary.

 Adopts the Gigabit Ethernet port, which can connect to the PC.

Software design:

 Supports pixel level brightness and chroma calibration.

 Supports setting of images pre-stored in the receiving card.

 Supports status detection of temperature, voltage, Ethernet cable communication and video source signals.

 Supports the 5-pin LCD module.

Availability: In stock

Qty:

Specifications
Dimension
Light Distribution
Photometric Diagram
Other

รหัสสินค้า	MRV328	คุณสมบัติของสินค้า	Supporting pixel level brightness and chroma calibration : Brightness and chroma calibration on NovaLCT for each pixel could remove color difference effectively, make the brightness and chroma of the whole screen highly consistent, and improve the display effect. Supporting setting of images pre-stored in the receiving card : On NovaLCT, the specified images could be set as the screen startup image and images used when the Ethernet cable is disconnected or no video source signal is available. Supporting status detection of temperature, voltage, Ethernet cable communication and video source signals : On NovaLCT, the status of receiving card's temperature, voltage, Ethernet cable communication and video source signals can be detected. Supporting LCD module :Supports NovaStar's general 5-pin LCD module. The LCD module is connected to the HUB board to display temperature, voltage, single operating time and total operating time of the receiving card. Supporting readback of configuration file : On NovaLCT, the configuration information stored in the receiving card can be read back. Supporting readback of firmware version : On NovaLCT, the firmware versions of the receiving card can be read back.
ตัวชี้วัด	Flashes every other 1s. : No sending card mode: The receiving card works normally with no sending card connected. Ethernet cable connection is normal, and video source input is available. Flashes every other 0.5s. : Sending card mode: Both the receiving card and the sending card work normally. Ethernet cable connection is normal, and video source input is available. Flashes every other 3s. : The receiving card works normally while the Ethernet cable connection is abnormal. Rapidly flashes for 3 times every other 3s. : The receiving card works normally and Ethernet cable connection is normal, while no video source input is available. Rapidly flashes every other 0.2s. : Program loading fails in normal operating and the device is coming to the backup operating state. Always on : The indicator will be always on after the power is on.	อินเทอร์เฟซข้อมูล	GND / 16 15 HOE HLAT / 14 13 HDCLK HD / 12 11 HC HB / 10 9 HA HE / 8 7 B G / 6 5 R GND / 4 3 B G / 2 1 R
แรงดันไฟฟ้าเข้า	DC 3.3 V–5.0 V	พิกัดกระแสของมอเตอร์ดีซี	0.5 A
ความเข้มของการส่องสว่าง	2.5 W	อุณหภูมิในการทำงาน	-20°C–70°C
อุณหภูมิใช้งานปกติ	-25°C –125°C	ความชื้นในการทำงาน	10% RH–90% RH
ขนาด	144.0 mm x 91.5 mm x 16.0 mm	น้ำหนักสุทธิ	85.5 g
มาตราฐานการรับรอง	RoHS	การบรรจุ	An antistatic bag and anti-collision foam are prepared for each receiving card. Dimensions of the packing box: 650.0 mm x 500.0 mm x 200.0 mm, 100 receiving cards in each box.

no data to display

Downloads

Receiving-Card-MRV328-Product-Deion-V1.0.0
