รหัสสินค้า | NovaPro HD | แหล่งสัญญาณเข้า | CVBS : Qty 1 / PAL/NTSC VGA : Qty 1 / VESA standard DVI : Qty 1 / VESA standard (1080i input supported) Supports HDCP. HDMI : Qty 1 / EIA/CEA-861 standard, conforming to HDMI-1.3 standard Supports HDCP. DP : Qty 1 / VESA standard 3G-SDI : Qty 1 / 480i, 576i, 720p, 1080i/p (3G SDI) |
สัญญาณออก | DVI LOOP : Qty 1 / DVI loop output, consistent with DVI input connector SDI LOOP : Qty 1 / SDI loop output, consistent with SDI input connector LED Output : Qty 4 / 4 Gigabit Ethernet outputs. Only Ethernet port 1 supports audio output. When the multifunction card is connected for audio decoding, the multifunction card must be connected to the Ethernet port 1. Maximum horizontal resolution is 3840 pixels. Maximum vertical resolution is 1920 pixel OPT Output : Qty 4 / 4 optical fiber connectors for long-distance transmission Monitor : Qty 2 DVI and HDMI connectors for output image monitoring DVI and HDMI connectors output the same image. |
ตัวจ่ายพลังงานไฟ | 100~250 VAC, 50/60 Hz, 0.65 A |
ข้อมูลโดยรวม | Input power : 100~250 VAC, 50/60 Hz, 0.65 A Overall power consumption : 30 W Operating temperature : -20~60℃ Weight : 6 kg |
